SSP Universal Millguard

SSP Universal Millguard
SSP Universal Millguard SSP Universal Millguard SSP Universal Millguard SSP Universal Millguard
  • Machine Type - Universal / Turret CNC
  • Method of attachment - Is by adjustable parallel rails which are T bolted to table slots allowing the guard to be positioned forward around vice or component
  • Single interlock and positive manual latch
  • Construction - Steel tubular frame and 5mm polycarbonate windows
  • A guarding package complete with infilling swarf tray to comply with environmental regulations is available
  • Rear Swarf Guard - Helps to contain the flying swarf within the table area and also act as a deterrent against third party intervention from the rear. (We do not produce the rigid type show in our photograph now)
  • Operation - Totally encloses front and side of machine table. Slide and fold back front windows giving access to the work area. Hinged side windows to expose both end of machine table to allow machining of components that extend beyond table length. The right hand side of guard has additional sliding windows to give access to turret or machine console

For additional technical information on our lathe guards, drill guards, miller and grinder guards please email or call 01709 578222, we will be happy to help.

  Maximum Table Size Minimum Table Size Left Hand Side Window Right Hand Side Window Front Right Hand Sliding Window
SSP1 1185 500mm 500 x 460 500 x 460 max adj to 275 min 320 x 222 ht.
SSP2 1585* 1100mm 500 x 460 500 x 460 max adj to 275 min 320 x 222 ht.
